DBA52844.1XD

Řada 5000 – Vrtané křížem, drážkované a s prohlubněmi – pouze rotor

Diameter [mm]	370
Thickness [mm]	34
Disc Vent	Kangaroo Paw
Annulus [mm] (Maximum useable pad width)	59
Pitch Circle Diameter (P.C.D.)	228,6
Inside Diameter [mm]	251,8
Diameter & Number of Bolt Holes [mm]	6.4 (x12)
Air Gap [mm]	13
Offset [mm]	0
Flange Inside Diameter [mm]	210
Flange Thickness [mm]	7
Hole Type	Elongated Hole
Stage	Stage 5
Tech Bulletins	Bedding in Brakes
Tech Bulletins	How to clean a Disc Rotor before fitting
Tech Bulletins	Motorsport - Important Info
Replacement Nuts	Included
