DBA52018.1

Řada 5000 – hladký povrch – pouze rotor

Diameter [mm]	350
Thickness [mm]	32
Disc Vent	Kangaroo Paw
Annulus [mm] (Maximum useable pad width)	56,5
Pitch Circle Diameter (P.C.D.)	215,9
Inside Diameter [mm]	237
Diameter & Number of Bolt Holes [mm]	6.4 (x12)
Air Gap [mm]	16
Offset [mm]	0
Flange Inside Diameter [mm]	200
Flange Thickness [mm]	6,35
Hole Type	Round Hole
Stage	Stage 5
Tech Bulletins	Bedding in Brakes
Tech Bulletins	How to clean a Disc Rotor before fitting
Tech Bulletins	Motorsport - Important Info
Replacement Nuts	Included
